Axagon ADE-25R

Produkt

Tillverkare

Axagon

Produktnamn

ADE-25R

Tillverkarens länk

https://www.axagon.eu/en/produkty/ade-25r

Produktkoder

Tillverkarens produktkoder

• ADE-25R

GTIN- / EAN-koder

• 8595247906601

Produktbilder

Ports & interfaces

Connectivity technology

Wired

Host interface

USB

Interface

Ethernet

Ethernet LAN (RJ-45) ports

1

USB version

2.0/3.2 Gen 1 (3.1 Gen 1)

Network

Maximum data transfer rate

2500 Mbit/s

Networking standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Ethernet LAN

Ja

Ethernet interface type

Gigabit Ethernet

Ethernet LAN data rates

10,100,1000,2500 Mbit/s

Wake-on-LAN ready

Ja

Full duplex

Ja

Jumbo frames support

Ja

VLAN support

Ja

Design

Internal

Nej

Component for

PC/Laptop

Product colour

Grey

Chipset

Realtek RTL8156B

Plug and Play

Ja

LED indicators

Ja

Country of origin

China

Certification

CE, RoHS

Compatible products

IEEE 802.3ab 1000Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3 10Base-T

Power

USB powered

Ja

System requirements

Windows operating systems supported

Ja

Mac operating systems supported

Ja

Linux operating systems supported

Ja

Server operating systems supported

Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016

Weight & dimensions

Width

64 mm

Depth

24 mm

Height

14 mm

Weight

26 g

Packaging data

Quantity per pack

1 pc(s)

Package type

Box

Package width

180 mm

Package depth

90 mm

Package height

25 mm

Package weight

60 g

Packaging content

Cables included

USB Type-A

Manual

Ja

Technical details

Warranty period

3 year(s)

Compliance certificates

RoHS, CE

Other features

Housing material

Metal

Data transfer rate

2.5 Gbit/s

Cable length

0.15 m
