Lenovo ThinkPad P14s Gen 7 (Intel)

Produkt

Tillverkare

Lenovo

Produktfamilj / -serie

ThinkPad P

Produktnamn

ThinkPad P14s Gen 7 (Intel)

Tillverkarens länk

https://www.lenovo.com/se/sv/p/laptops/thinkpad/thinkpadp/leno..

Produktkoder

Tillverkarens produktkoder

• 21XJ000XMX

Produktbilder

Design

Product type

Mobile workstation

Product colour

Black

Form factor

Clamshell

Housing material

Aluminium

Display back cover material

Aluminium

Display

Display diagonal

14.5 "

Display resolution

1920 x 1200 pixels

Touchscreen

Nej

HD type

WUXGA

Panel type

IPS

LED backlight

Ja

Native aspect ratio

16:10

Anti-glare screen

Ja

Display brightness

400 cd/m²

RGB colour space

NTSC

Colour gamut

45 %

Maximum refresh rate

60 Hz

Contrast ratio (typical)

1000:1

Processor

Processor manufacturer

Intel

Processor family

Intel Core Ultra X9

Processor generation

Intel® Core™ Ultra (Series 3)

Processor model

388H

Processor cores

16

Processor threads

16

Processor boost frequency

5.1 GHz

Performance cores

4

Efficient cores

8

Low Power Efficient-cores

4

Performance-core Max Turbo Frequency

5.1 GHz

Efficient-core Max Turbo Frequency

3.8 GHz

Low Power Efficient-core Max Turbo Frequency

3.7 GHz

Performance-core base frequency

2.1 GHz

Efficient-core base frequency

1.6 GHz

Low Power Efficient-core Base Frequency

1600 MHz

Processor cache

18 MB

Processor cache type

Smart Cache

Processor socket

FCBGA2540

Processor base power

25 W

Maximum turbo power

80 W

Neural processor unit (NPU)

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Ja

Windows Studio effects support

Ja

AI software frameworks supported by NPU

OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

50 TOPs

GPU performance up to

122 TOPs

Memory

Internal memory

32 GB

Internal memory type

LPDDR5x-SDRAM

Memory clock speed

8533 MHz

Memory form factor

LPCAMM2

Maximum internal memory

96 GB

Memory channels

Dual-channel

Storage

Total storage capacity

1000 GB

Storage media

SSD

Total SSDs capacity

1000 GB

Number of SSDs installed

1

SSD capacity

1000 GB

SSD interface

PCI Express 4.0

NVMe

Ja

SSD form factor

M.2

M.2 SSD size

2280 (22 x 80 mm)

Optical drive type

Nej

Card reader integrated

Nej

Graphics

On-board graphics card

Ja

Discrete graphics card

Nej

Discrete graphics card model

Not available

On-board GPU manufacturer

Intel

On-board graphics card family

Intel Arc Graphics

On-board graphics card model

Intel Arc B390

Ray tracing acceleration

Ja

Audio

Audio system

Dolby Atmos

Number of built-in speakers

2

Speaker power

2 W

Built-in microphone

Ja

Number of microphones

2

Camera

Front camera

Ja

Front camera resolution (numeric)

5 MP

Infrared (IR) camera

Ja

Privacy camera

Ja

Privacy type

Privacy shutter

Network

Mobile network connection

Nej

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

Wi-Fi standards

Wi-Fi 7 (802.11be)

Antenna type

2x2

WLAN controller model

Intel Wi-Fi 7 BE211

WLAN controller manufacturer

Intel

Ethernet LAN

Ja

Ethernet LAN data rates

100,1000 Mbit/s

Bluetooth

Ja

Bluetooth version

5.4

Near Field Communication (NFC)

Nej

WWAN

Upgradable

Ports & interfaces

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

Ethernet LAN (RJ-45) ports

1

HDMI ports quantity

1

HDMI version

2.1

Thunderbolt 4 ports quantity

2

Intel® Thunderbolt 4

Ja

Combo headphone/mic port

Ja

USB Type-C DisplayPort Alternate Mode

Ja

USB Sleep-and-Charge

Ja

USB Sleep-and-Charge ports

1

Performance

Motherboard chipset

Intel SoC

Keyboard

Pointing device

ThinkPad UltraNav

Numeric keypad

Nej

Keyboard backlit

Ja

Spill-resistant keyboard

Ja

Keyboard language

Nordic

Copilot key

Ja

Software

Operating system installed

Windows 11 Pro

Operating system architecture

64-bit

Operating system language

English, Finnish, Danish, Norwegian, Swedish

Bundled software

Intel Connectivity Performance Suite + Lenovo AI Now

Battery

Battery technology

Lithium-Ion (Li-Ion)

Battery capacity

75 Wh

Fast charging

Ja

Power

AC adapter power

100 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

USB Type-C charging port

Ja

USB Power Delivery (USB PD)

Ja

Security

Cable lock slot

Ja

Cable lock slot type

Kensington

Fingerprint reader

Ja

Smart card reader

Nej

Windows Hello

Ja

Trusted Platform Module (TPM)

Ja

Trusted Platform Module (TPM) version

2.0

Password protection

Ja

Password protection type

Power on, SSD, Supervisor

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Storage temperature (T-T)

5 - 43 °C

Operating relative humidity (H-H)

8 - 95 %

Storage relative humidity (H-H)

5 - 95 %

Maximum shipping altitude

3048 m

Certificates

Certification

ENERGY STAR® 9.0 EPEAT™ Gold Registered RoHS compliant TCO Certified, generation 10

Weight & dimensions

Weight

1630 g

Width

325.2 mm

Depth

226.3 mm

Height (front)

11.7 mm

Height (rear)

16.22 mm

Packaging content

AC adapter included

Ja
