Ubiquiti UniFi Flex 2.5G

Produkt

Tillverkare

Ubiquiti

Produktfamilj / -serie

UniFi

Produktnamn

Flex 2.5G

Tillverkarens länk

https://eu.store.ui.com/eu/en/category/switching-utility/produ..

Produktkoder

Tillverkarens produktkoder

• USW-FLEX-2.5G-8

GTIN- / EAN-koder

• 0810084695951
• 0810084696057

Produktbilder

Management features

Switch type

Managed

Switch layer

L2

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

8

Basic switching RJ-45 Ethernet ports type

2.5G Ethernet (100/1000/2500)

2.5G Ethernet (copper) ports quantity

8

10G Ethernet (copper) ports quantity

1

SFP+ module slots quantity

1

Network

10G support

Ja

Port mirroring

Ja

Flow control support

Ja

Broadcast storm control

Ja

Rate limiting

Ja

Ethernet LAN data rates

10,100,1000,2500 Mbit/s

VLAN support

Ja

Number of VLANs

256

Data transmission

MAC address table

4000 entries

Switching capacity

60 Gbit/s

Throughput

30 Gbit/s

Forwarding rate

45 Mpps

Jumbo frames support

Ja

Security

Loop protection

Ja

Multicast features

Multicast support

Ja

Design

Form factor

Desktop/Wall-Mounting

Product colour

White

Housing material

Polycarbonate (PC)

LED indicators

Activity, Link, Power, Status

Wall mountable

Ja

DIN rail mounting

Ja

Power

Power source

PoE/USB

Power supply included

Nej

Input current

3.9 A

Power consumption (max)

17 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)

Nej

Operational conditions

Operating temperature (T-T)

-20 - 45 °C

Operating relative humidity (H-H)

10 - 90 %

Weight & dimensions

Width

212.9 mm

Depth

99.4 mm

Height

33.5 mm

Weight

567 g

Certificates

Compliance certificates

CE, Federal Communications Commission (FCC), Industry Canada (IC)
