APC GVSUPS10KB4HS

Produkt

Tillverkare

APC

Produktnamn

GVSUPS10KB4HS

Tillverkarens länk

https://www.apc.com/shop/rw/en/products/Galaxy-VS-UPS-10kW-400..

Produktkoder

Tillverkarens produktkoder

• GVSUPS10KB4HS

GTIN- / EAN-koder

• 0731304406730
• 5705154232790

Produktbilder

Features

UPS topology

Double-conversion (Online)

Output power capacity

10 kVA

Output power

10000 W

Waveform

Sine

Input operation voltage (min)

340 V

Input operation voltage (max)

460 V

Input frequency

40/70 Hz

Output operation voltage (min)

380 V

Output operation voltage (max)

415 V

Output frequency

50/60 Hz

Maximum current

18 A

Number of input phases

3

Number of output phases

3

Input power factor

0.99

Crest factor

2.5:1

ECO mode

Ja

Output voltage Total Harmonic Distortion (THD)

3 %

Input current Total Harmonic Distortion (THD)

3 %

Noise level

55 dB

Power protection features

Overload, Short circuit

Audible alarm(s)

Ja

Ports & interfaces

AC outlet types

Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G)

SmartSlot

Ja

SmartConnect port

Nej

Battery

Battery technology

Sealed Lead Acid (VRLA)

Battery voltage

480 V

Design

Form factor

Tower

Product colour

White

Display type

LCD

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-15 - 40 °C

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Operating altitude

0 - 1000 m

Non-operating altitude

0 - 3000 m

Certificates

Certification

CSA C22.2 NO. 107.3, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IEC 60721-4-2 Level 2M2, UL 1778 5th edition

Packaging content

Management card included

Ja

Quick installation guide

Ja

Weight & dimensions

Width

521 mm

Depth

847 mm

Height

1485 mm

Weight

330000 g

Packaging data

Package width

640 mm

Package depth

990 mm

Package height

1680 mm

Package weight

360000 g

Logistics data

Harmonized System (HS) code

85078000
