Synology DiskStation DS3622XS++ 6x12TB HDD

Produkt

Tillverkare

Synology

Produktfamilj / -serie

DiskStation

Produktnamn

DS3622XS++ 6x12TB HDD

Tillverkarens länk

https://www.synology.com/en-global/products/DS3622xs+

Produktkoder

Tillverkarens produktkoder

• DS3622XS+/72T/6X12T

Produktbilder

Storage

Storage drives installed

Ja

Total installed storage capacity

72 TB

Number of storage drives installed

6

Number of storage drives supported

12

Installed storage drive type

HDD

Supported storage drive types

HDD & SSD

Storage drive capacity

12000 GB

Storage drive interface

Serial ATA II, Serial ATA III

Supported storage drive interfaces

Serial ATA II, Serial ATA III

Storage drive sizes supported

2.5,3.5 "

RAID support

Ja

RAID levels

0, 1, 5, 6, 10, F1, JBOD

Online RAID migration

Ja

Online RAID expansion

Ja

Hot-swap drive bays

Ja

Supported file systems

BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4

Processor

Processor manufacturer

Intel

Processor family

Intel® Xeon® D

Processor model

D-1531

Processor frequency

2.2 GHz

Processor boost frequency

2.7 GHz

Processor cores

6

CPU configuration (max)

1

Memory

Internal memory

16 GB

Internal memory type

DDR4

Memory clock speed

2666 MHz

Maximum RAM supported

48 GB

Memory slots

4

Memory form factor

SO-DIMM

ECC

Ja

Network

Ethernet LAN

Ja

Ethernet LAN data rates

10,100,1000,10000 Mbit/s

Ethernet LAN data rate supported (max)

10000 Mbit/s

iSCSI support

Ja

Wake-on-LAN ready

Ja

Supported network protocols

SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

USB port

Ja

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

PCI Express x8 (Gen 3.x) slots

1

Design

Chassis type

Desktop

Cooling type

Active

Product colour

Black

Number of fans

2 fan(s)

Fan diameter

120 mm

Fan diameter 2

120 mm

Drive bay locking

Ja

LED indicators

Ja

Performance

Type

NAS

Device class

Small & Medium Business

Backup function

Ja

Backup features

Cloud, iSCSI LUN

Noise level

25 dB

Third-party support

Ja

Snapshot

Ja

Security algorithms

HTTPS, SSL/TLS

Access Control List (ACL)

Ja

Reset button

Ja

On/off switch

Ja

Built-in iTunes server

Ja

Built-in FTP server

Ja

Browser supported

Google Chrome, Firefox, Microsoft Edge, Safari

System log

Ja

Hot spare

Ja

Share folder

SMB/AFP/NFS/FTP/WebDAV

Software

Operating system installed

DiskStation Manager

Windows operating systems supported

Ja

Linux operating systems supported

Ja

Mac operating systems supported

Ja

Power

Power supply location

Built-in

Power supply unit (PSU) capacity

550 W

Number of power supply units

1

Power consumption (HDD standby)

54.33 W

AC input voltage

100 - 240 V

AC input frequency

50 /60 Hz

Weight & dimensions

Width

300 mm

Depth

340 mm

Height

270 mm

Packaging content

Cables included

AC, LAN (RJ-45)

Power cables quantity

1

Sustainability

Sustainability compliance

Ja

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95 %

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

5 - 95 %

Operating altitude

0 - 5000 m

Other features

Compliance certificates

CE, RoHS

Certification

FCC, BSMI, VCCI, RCM, UKCA, EAC, KC, UL
