Lian Li SP0750G.W

Produkt

Tillverkare

Lian Li

Produktnamn

SP0750G.W

Tillverkarens länk

https://lian-li.com/product/sp-v2/?utm_source=chatgpt.com

Produktkoder

Tillverkarens produktkoder

• G9P.SP0750G.W000.EU

GTIN- / EAN-koder

• 4718466018434

Produktbilder

Power

Total power

750 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

5 - 10 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

100 W

Combined power (+12V)

744 W

Combined power (+5V)

100 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

20 A

Max output current (+12V)

62 A

Max output current (+5V)

20 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Efficiency

90 %

Power protection features

No load operation, Over current, Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under temperature, Under voltage

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

350 mm

Number of SATA power connectors

7

SATA power cable length

350 mm

Peripheral (Molex) power connectors (4-pin)

1

EPS power connector (8-pin)

Ja

PCI Express power connectors (6+2 pin)

2

PCI Express power connectors (8-pin)

1

PCI Express power cable length

400 mm

CPU power connector (4+4 pin)

Ja

CPU power cable length

600 mm

Cabling type

Fully-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

SFX

80 PLUS certification

80 PLUS Gold

ATX version

3.1

Noise level

32.5 dB

Bearing technology

FDB

Design

Product colour

White

Cooling type

Active

Fan diameter

92 mm

Number of fans

1 fan(s)

Fan speed

0 - 3000 RPM

On/off switch

Ja

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Weight & dimensions

Width

125 mm

Depth

100 mm

Height

63.5 mm
