Brother ADS-4700W

Produkt

Tillverkare

Brother

Produktnamn

ADS-4700W

Tillverkarens länk

https://www.brother.eu

Produktkoder

Tillverkarens produktkoder

• ADS4700WRE1
• ADS4700WTF1

GTIN- / EAN-koder

• 4977766814713
• 4977766814737

Produktbilder

Scanning

Maximum scan size

215.9 x 355.6 mm

Optical scanning resolution

600 x 600 DPI

Enhanced scan resolution

1200 x 1200 DPI

Colour scanning

Ja

Duplex scanning

Ja

Input colour depth

48 bit

Output colour depth

24 bit

Output greyscale depth

8 bit

Greyscale levels

256

ADF scan speed (b/w, A4)

40 ppm

ADF scan speed (colour, A4)

40 ppm

Duplex ADF scan speed (b/w, A4)

80 ipm

Duplex ADF scan speed (colour, A4)

80 ipm

Design

Scanner type

ADF + Sheet-fed scanner

Built-in display

Ja

Product colour

Black, White

Display

LCD

Display diagonal

4.3 "

Touchscreen

Ja

Colour display

Ja

Control type

Touch

Performance

Sensor type

Dual CIS

Light source

LED

Scan file formats

JPEG, PDF, TIFF

Daily duty cycle (max)

6000 pages

Maximum duty cycle

120000 pages per month

Scan to

E-mail Server, FTP, File, HTTP, PC, SMB

Scan drivers

ISIS, TWAIN, WIA

Ultrasonic sensor

Ja

Scanning noise level

59 dB

Input capacity

Auto document feeder (ADF) input capacity

80 sheets

Paper handling

Maximum ISO A-series paper size

A4

Scanning media types supported

Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper

Long-paper mode

Ja

Legal

Ja

Media thickness (min)

0.28 mm

Card thickness (max)

1.32 mm

Paper tray media weight

40 - 200 g/m²

Maximum scan width

215.9 mm

Maximum scan length

5000 mm

Ports & interfaces

USB port

Ja

USB version

2.0/3.2 Gen 1 (3.1 Gen 1)

Network

Wi-Fi

Ja

Wi-Fi standards

802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ethernet LAN

Ja

Security algorithms

64-bit WEP, 128-bit WEP, 802.1x RADIUS, EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, HTTPS, SMTP-AUTH, SNMPv3, SSL/TLS, TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA3, WPS

IPv6 support

Ja

Supported network protocols

DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP, RA, ICMPv6

Power

Power supply type

AC

Power consumption (typical)

26 W

Power consumption (standby)

2.1 W

Power consumption (off)

0.1 W

Sleep mode

Ja

Power consumption (sleep)

1.7 W

Output voltage

24 V

Output current

1.9 A

Auto power off

Ja

Weight & dimensions

Width

299.5 mm

Depth

215.9 mm

Height

190.5 mm

Weight

2750 g

Packaging data

Quantity per pack

1 pc(s)

Package width

391 mm

Package depth

243 mm

Package height

320 mm

Package weight

3460 g

System requirements

Windows operating systems supported

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 x64, Windows 8.1, Windows 8.1 x64

Mac operating systems supported

Ja

Linux operating systems supported

Ja

Server operating systems supported

Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

20 - 80 %

Storage relative humidity (H-H)

10 - 90 %

Other features

Cable lock slot

Ja

Certification

GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0
