HPE ProLiant DL20 Gen11

Produkt

Tillverkare

HPE

Produktfamilj / -serie

ProLiant DL

Produktnamn

ProLiant DL20 Gen11

Lanseringsdatum

06.10.2025

Tillverkarens länk

https://www.hpe.com/

Produktkoder

Tillverkarens produktkoder

• P87466-425

GTIN- / EAN-koder

• 0190017826394

Produktbilder

Processor

Processor manufacturer

Intel

Processor family

Intel® Xeon®

Processor model

6333P

Processor frequency

3.1 GHz

Processor boost frequency

5.2 GHz

Performance cores

6

Processor cores

6

Processor cache

18 MB

Number of processors installed

1

Processor cache type

L3

Memory

Internal memory

32 GB

Internal memory type

DDR5-SDRAM

Memory slots

4x DIMM

Memory clock speed

4800 MHz

Memory layout (slots x size)

1 x 32 GB

Maximum internal memory

128 GB

Storage

Total storage capacity

960 GB

Number of SSDs installed

2

SSD capacity

480 GB

SSD interface

SATA III

Supported SSD sizes

2.5"

Number of SSDs supported

4

RAID support

Ja

Supported RAID controllers

Embedded Intel VROC SATA (formerly known as Intel RSTe)

Optical drive type

Nej

Graphics

On-board graphics card

Nej

On-board graphics card model

Not available

Network

LAN controller

Broadcom BCM5719

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

5

VGA (D-Sub) ports quantity

1

DisplayPorts quantity

1

Expansion slots

Two maximum, for detailed descriptions refer to the QuickSpecs.

Design

Chassis type

Rack (1U)

Product colour

Black, Silver

Cooling type

Active

Rack mounting

Ja

Performance

Management platform

HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management (optional subscription available)

Trusted Platform Module (TPM)

Ja

Trusted Platform Module (TPM) version

2.0

Software

Operating system installed

Nej

Power

Redundant power supply (RPS) support

Ja

Power supply type

1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Power supply

1000 W

Number of main power supplies

1

Weight & dimensions

Width

434.6 mm

Depth

378.4 mm

Height

43.2 mm

Other features

Security features

Embedded Trusted Platform Module (TPM) 2.0 enabled by default. For servers shipping to China, the TPM is disabled. For full security features refer to the QuickSpecs.

Number of processors supported

1

Standard fans

3x High Performance Fans

Storage drive type

2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
