GIGABYTE AORUS ELITE P850W

Produkt

Tillverkare

GIGABYTE

Produktnamn

AORUS ELITE P850W

Tillverkarens länk

https://www.gigabyte.com/uk/Power-Supply/GP-AE850PM-PG5-rev-10..

Produktkoder

Tillverkarens produktkoder

• GP-AE850PM PG5
• GP-AE850PM PG5 EU

GTIN- / EAN-koder

• 4719331554262

Produktbilder

Power

Total power

850 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

12 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

125 W

Combined power (+12V)

849.6 W

Combined power (+5V)

125 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

25 A

Max output current (+12V)

70.8 A

Max output current (+5V)

25 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Hold time

16 ms

Efficiency

90 %

Power Good signal delay range

100 - 150 ms

Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

650 mm

Number of SATA power connectors

8

Peripheral (Molex) power connectors (4-pin)

4

PCI Express power connectors (6+2 pin)

6

CPU power connector (4+4 pin)

Ja

ATX power connector (20+4 pin)

Ja

Floppy drive power connector

2

Floppy disk drive connector

Ja

PCI Express connector

Ja

Cabling type

Fully-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Platinum

ATX version

3.1

Bearing technology

Ball bearing

Mean time between failures (MTBF)

100000 h

Design

Product colour

Black

Cooling type

Active

Fan diameter

120 mm

Number of fans

1 fan(s)

Fan location

Top

On/off switch

Ja

Weight & dimensions

Width

150 mm

Depth

140 mm

Height

86 mm

Weight

2674 g

Packaging data

Package width

340 mm

Package depth

206 mm

Package height

120 mm

Package weight

3302 g

Package type

Box

Logistics data

Warranty period

10 year(s)
