Philips S Line 243S1/00

Produkt

Tillverkare

Philips

Produktfamilj / -serie

S Line

Produktnamn

243S1/00

Tillverkarens länk

https://mmdmonitors.com/

Produktkoder

Tillverkarens produktkoder

• 243S1/00

GTIN- / EAN-koder

• 8712581784744

Produktbilder

Display

Display diagonal

23.8 "

Display resolution

1920 x 1080 pixels

Native aspect ratio

16:9

Display technology

LCD

Touchscreen

Nej

HD type

Full HD

Panel type

IPS

LED backlight

Ja

Backlight type

W-LED

Display brightness (typical)

300 cd/m²

Response time

4 ms

Display surface

Matt

Anti-glare screen

Ja

Screen shape

Flat

Aspect ratio

16:9

Contrast ratio (typical)

1000:1

Contrast ratio (dynamic)

50000000:1

Dynamic contrast ratio marketing name

SmartContrast

Maximum refresh rate

75 Hz

Viewing angle, horizontal

178 °

Viewing angle, vertical

178 °

Display number of colours

16.7 million colours

Pixel pitch

0.2745 x 0.2745 mm

Pixel density

93 ppi

Horizontal scan range

30 - 85 kHz

Vertical scan range

48 - 100 Hz

Viewable size, horizontal

527.04 mm

Viewable size, vertical

296.46 mm

Display diagonal (metric)

60.5 cm

DDC/CI

Ja

Haze rate

25 %

Surface hardness

3H

Colour gamut standard

sRGB, NTSC

Colour gamut

91 %

sRGB coverage (typical)

107 %

NTSC coverage (typical)

91 %

Display sRGB

Ja

Display panel size

23.8 inch/60.5 cm

Performance

NVIDIA G-SYNC

Nej

AMD FreeSync

Nej

Fast charging

Ja

Fast charging technology

Power Delivery

Component video sync

Separate Sync

Flicker-free technology

Ja

Low Blue Light technology

Ja

Multimedia

Built-in speaker(s)

Ja

Number of speakers

2

RMS rated power

4 W

Built-in camera

Nej

Design

Market positioning

Office

Product colour

Black

Front bezel colour

Black

Feet colour

Black

Ports & interfaces

Built-in USB hub

Ja

USB hub version

3.2 Gen 2 (3.1 Gen 2)

USB upstream port type

USB Type-C

Number of upstream ports

1

USB Type-A downstream ports quantity

4

USB Type-C DisplayPort Alternate Mode

Ja

USB Power Delivery (USB PD)

Ja

USB Power Delivery up to

65 W

HDMI

Ja

HDMI ports quantity

1

HDMI version

1.4

DisplayPorts quantity

1

DisplayPort out quantity

1

DisplayPort version

1.2

Audio output

Ja

HDCP

Ja

HDCP version

1.4

DisplayPort output

Ja

I/O ports

USB-C 3.2 Gen 1 x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)

Network

Ethernet LAN

Ja

Ergonomics

VESA mounting

Ja

Panel mounting interface

100 x 100 mm

Cable lock slot

Ja

Cable lock slot type

Kensington

Height adjustment

Ja

Adjustable height (max)

130 mm

Pivot

Ja

Pivot angle

-90 - 90 °

Swivelling

Ja

Swivel angle range

-180 - 180 °

Tilt adjustment

Ja

Tilt angle range

-5 - 25 °

On Screen Display (OSD)

Ja

On Screen Display (OSD) languages

Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian

Number of OSD languages

21

Plug and Play

Ja

LED indicators

Operation, Stand-by

Power

Energy efficiency class (SDR)

D

Energy efficiency class (HDR)

Not available

Energy consumption (SDR) per 1000 hours

14 kWh

Power consumption (typical)

14 W

Power consumption (standby)

0.3 W

Power consumption (off)

0.3 W

Power consumption (PowerSave)

12.9 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Power supply type

Internal

Energy efficiency scale

A to G

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

20 - 80 %

Operating altitude

0 - 3658 m

Non-operating altitude

0 - 12192 m

Weight & dimensions

Width (with stand)

540 mm

Depth (with stand)

205 mm

Height (with stand)

482 mm

Weight (with stand)

5280 g

Width (without stand)

540 mm

Depth (without stand)

51 mm

Height (without stand)

323 mm

Weight (without stand)

3420 g

Packaging data

Package width

625 mm

Package depth

180 mm

Package height

435 mm

Package weight

8460 g

Packaging content

Stand included

Ja

Cables included

HDMI, DisplayPort, USB Type-C, AC

Manual

Ja

Bundled software

SmartControl

Sustainability

Sustainability certificates

ENERGY STAR, TCO

Doesn't contain

Mercury, PVC/BFR

Sustainability compliance

Ja

Other features

Compatible operating systems

Mac OS X; Windows 10/8.1/8/7

USB Power Delivery revision

3.0

Exterior finish type

Textured

Monitor sync input signal

Separate Sync

Heavy metals free

Hg (mercury)

EasyRead mode

Ja

LowBlue mode

Ja

Energy efficiency class (legacy scale)

D

Compliance certificates

RoHS

Mean time between failures (MTBF)

70000 h

Ethernet LAN data rates

10,100,1000 Mbit/s

Certification

CB, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, EAEU RoHS, TUV Eye Comfort certified

User controls

SmartImage; Input; Brightness; Menu; Power On/Off

Picture enhancement

SmartImage

Regulatory Approvals

CB; FCC Class B; ICES-003; CE Mark; TUV/GS; TUV Ergo; CU-EAC; EAEU RoHS; TUV Eye Comfort certified

Wake-on-LAN

Ja

Recycling data

Packaging recyclability rate

100 %

Product post-consumer recycled plastic

85 %

Technical details

Native refresh rate

60 Hz

Logistics data

Harmonized System (HS) code

85285210
