HPE ProLiant DL320 Gen12

Produkt

Tillverkare

HPE

Produktfamilj / -serie

ProLiant DL

Produktnamn

ProLiant DL320 Gen12

Lanseringsdatum

01.12.2025

Tillverkarens länk

https://www.hpe.com/

Produktkoder

Tillverkarens produktkoder

• P87775-425

GTIN- / EAN-koder

• 0190017827186
• 4549821660964

Produktbilder

Processor

Processor manufacturer

Intel

Processor family

Intel® Xeon®

Processor model

6515P

Processor frequency

2.3 GHz

Processor boost frequency

3.8 GHz

Processor cores

16

Processor cache

72 MB

Number of processors installed

1

Processor cache type

L3

Memory

Internal memory

64 GB

Internal memory type

DDR5-SDRAM

Memory slots

16x DIMM

Memory clock speed

6400 MHz

Memory layout (slots x size)

1 x 64 GB

Maximum internal memory

4000 GB

Storage

Supported SSD sizes

2.5"

Number of SSDs supported

8

RAID support

Ja

Supported RAID controllers

HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller HPE NS204i-u v2 480GB NVMe Hot Plug Boot Optimized Storage Device

Optical drive type

Nej

Graphics

On-board graphics card

Nej

On-board graphics card model

Not available

Network

LAN controller

Broadcom BCM57416

Ethernet LAN

Ja

Ethernet interface type

10 Gigabit Ethernet

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

3

VGA (D-Sub) ports quantity

1

Number of management ports

1 pc(s)

Expansion slots

Up to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor, for detailed descriptions reference the QuickSpecs

Design

Chassis type

Rack (1U)

Product colour

Black

Cooling type

Active

Rack mounting

Ja

Performance

Management platform

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (optional subscription available)

Trusted Platform Module (TPM)

Ja

Trusted Platform Module (TPM) version

2.0

Software

Operating system installed

Nej

Power

Redundant power supply (RPS) support

Ja

Power supply type

2x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit

Power supply

1000 W

Number of main power supplies

2

Weight & dimensions

Width

607.5 mm

Depth

434.6 mm

Height

42.8 mm

Other features

Security features

UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Intel Trust Domain Extensions (Intel TDX). Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.

Number of processors supported

1

Standard fans

7x High Performance Fans

Storage drive type

None ship standard, 8 SFF supported
